SL-2000-P Brand APC By Apollo Smoke Detectors

The SL-2000-P smoke detector by APC by Apollo — one of the globally trusted smoke detector brands from the USA — is a reliable solution for modern fire protection systems.

SL-2000-P Duct Smoke Detector by APC By Apollo

1. Why is the SL-2000-P the top choice in Vietnam?

APC by Apollo is a US-based brand renowned worldwide for its smart fire detection solutions. The SL-2000-P is specially designed for the Asian market, offering internationally certified safety and quality (UL & CUL, CSFM) at a more competitive price.

SL-2000-P Duct Smoke Detector

This detector features:

• Photoelectric sensing – for fast smoke detection.
• Combined heat and smoke sensing – to enhance sensitivity while minimizing false alarms.
• Compatibility with both local and zoned fire alarm systems.

2. A Critical Role in Building Fire Protection Systems

🔸 Early Fire Detection – A Lifesaving Factor
As the first line of defense in fire safety, the SL-2000-P quickly detects smoke within seconds, enabling:

• Timely evacuation of occupants and staff.
• Automatic activation of alarms, lights, and fire suppression systems (e.g., sprinklers, gas).
• Signal transmission to the control panel for responsive actions.

🔸 Minimizing Damage and Risk
Early warning and response help:

• Prevent the spread of fire throughout the building.
• Protect assets, documents, and equipment in offices and factories.
• Reduce legal risks for building owners and managers.

🔸 Smart Integration with Building Management Systems (BMS)
APC smoke detectors integrate with BMS via addressable signals, allowing:

• Real-time monitoring of device status.
• Quick localization of the fire zone for precise emergency response.
• Automatic control of elevators, fire doors, and pressurization fans.

3. Key Features of the SL-2000-P

🔸 Flexible Output Signals
Supports both addressable and conventional systems with separate output terminals:

• Terminals 6 & 7: Fire alarm relay contacts (NO/NC).
• Terminal 12: Activates the “Common Shutdown” output – used to shut off HVAC during fire.
• Terminals 13 & 14: Technical fault relay (for error or power loss conditions).

🔸 Supports up to 30 devices on a single shutdown loop
🔸 Built-in LED Status Indicators
Easily check the status – power, alarm, fault, or maintenance needed.

🔸 Magnet Test Function
Hold a magnet to the designated area on the detector cover to simulate a fire alarm. The red LED lights up and output current increases, verifying system response.

4. Installation & Operation Guide for SL-2000-P

Step 1: Choose the Right Location

• Mount on horizontal ductwork where airflow is stable, away from bends, dampers, or fans.
• Ideal placement: at least 3 duct diameters before and after the sampling point.

Step 2: Install Sampling Tubes

• Adjustable to match airflow direction.
• Ensure red plug caps the intake tube (for smoke entry); blue cap on exhaust tube (for flow exit).

Step 3: Electrical Connections

• Power with 24VDC or 120/220VAC.
• Connect relay terminals according to fire alarm system diagram.
• For HVAC shutdown: Terminal 12 to control device; Terminal 20 supplies +24VDC.

Step 4: Test and Maintain

• Use a magnet to verify fire alarm function.
• Check fault LED to know when cleaning is needed.
• Regularly clean the fan, filter, and sensor to maintain performance.

5. DLK – Authorized Distributor of Apollo Smoke Detectors in Vietnam

Looking for genuine duct smoke detectors? DLK is your trusted partner in supplying sensors for fire alarm systems.
We offer a full range of smoke, CO, and CO₂ detectors suitable for all building types.

6. Contact DLK for Fire Alarm System Consultation

Don’t let fire hazards threaten your property. DLK is here to support your fire detection and alarm system needs.

• Address: G6/14 Tran Van Giau, Le Minh Xuan, Binh Chanh, HCMC
• Office: 111/7 Vuon Lai, Phu Tho Hoa, Tan Phu, HCMC
• Website: https://dlk.com.vn/l
• Email: info@dlk.com.vn
• Hotline: 070 357 0101 – 093 279 2697
