Specification
|
Description
|
|
Series ADPS
|
Adjustable Differential Pressure Switch
|
|
Service
|
Air and non-combustible, compatible gases.
|
|
Wetted Materials
|
Diaphragm material: Silicone. Housing material: PA 6.6 and POM.
|
|
Temperature Limits
|
Process/Ambient: -40 to 185°F (-40 to 85°C), for FM app.: max.140°F (60°C).
|
|
Pressure Limits
|
Max. operating pressure: 7.25 psi (500 mbar) for all pressure, switching pressure, and differential pressure ranges.
|
|
Switch Type
|
SPDT.
|
|
Electrical Rating
|
Standard: Max. 1.5 A (0.4 A) / 250 VAC, for FM app: 5 A / 125-250 VAC; Optional: Gold contact: max. 0.1A/24 VDC.
|
|
Electrical Connections
|
Push-on screw terminals. Cable strain relief: PG-9 (standard) or PG-11 (option).
|
|
Process Connections
|
2 plastic connection pieces, external Ø 0.24" (6.0 mm): Standard, for metal connection parts Ø 0.24" (6.0 mm) & 0.16" (4.0 mm) order accessory A-125 separately.
|
|
Mounting Orientation
|
Vertically, with pressure connections pointing downward.
|
|
Weight
|
4.6 oz (130 g) without bracket.
|
|
Agency Approvals
|
CE, RoHS.
|
|
Series EDPS
|
Adjustable Differential Pressure Switch
|
|
Service
|
Air and non-combustible, compatible gases.
|
|
Wetted Materials
|
Diaphragm material: Silicone; Housing material: PA 6.6 and POM.
|
|
Temperature Limits
|
Process/Ambient: -4 to 185°F (-20 to 85°C).
|
|
Pressure Limits
|
Max. operating pressure 2.89 psi (200 mbar) for pressure range .08-.4" w.c. (.2-1 mbar). Max. operating pressure 7.25 psi (500 mbar) for all other pressure, switching pressure and differential pressure ranges.
|
|
Switch Type
|
SPDT.
|
|
Electrical Rating
|
Standard: Max. 1.0 A/250 VAC; Optional: Gold contact: max. 0.1A/24 VDC.
|
|
Electrical Connections
|
Push-on screw terminals.
|
|
Process Connections
|
2 plastic connection pieces, external diameter 0.24" (6.0 mm).
|
|
Mounting Orientation
|
Vertically, with pressure connections pointing downwards.
|
|
Weight
|
2.1 oz (60 g) without bracket.
|
|
Agency Approvals
|
CE, RoHS.
|
|
Series BDPA
|
Adjustable Differential Pressure Switch
|
|
Service
|
Air and non-combustible, compatible gases.
|
|
Wetted Materials
|
Diaphragm: Silicone; Housing: PC and PA; Switch: PA6.6.
|
|
Temperature Limits
|
-4 to 185°F (-20 to 85°C).
|
|
Pressure Limits
|
Max. operating pressure 40" w.c. (100 mbar) for all pressure ranges. Burst pressure 200" w.c. (500 mbar).
|
|
Switch Type
|
SPDT.
|
|
Repeatability
|
±15% FS.
|
|
Electrical Rating
|
1 A (0.4) A / 250 VAC.
|
|
Electrical Connections
|
Screw terminals, PG-9 cable gland.
|
|
Process Connections
|
6.2 mm OD.
|
|
Mounting Orientation
|
Vertical, with pressure connections pointing downward.
|
|
Mechanical Working Life
|
>10^6 operations.
|
|
Weight
|
4 oz (113.4 g).
|
|
Enclosure Rating
|
IP65.
|
|
Agency Approvals
|
CE.
|
